Product Details:
Payment & Shipping Terms:
|
Warranty: | 3 Years | Protection Level: | IP65 |
---|---|---|---|
MPPT: | 460-850Vdc | Rated Output Current: | 29A |
Max.Efficiency: | 98% | Number Of String: | 3 |
Highlight: | solar water pump controller,deep well pump controller |
Max. Input DC voltage
|
880Vdc
|
Recommended MPPT voltage
|
460-850Vdc
|
Max. Input DC current
|
33.3A
|
Max. MPTT efficiency
|
99%
|
Number of Strings
|
3
|
Max. applicable motor output power
|
15KW
|
Rated output voltage
|
380-460Vac 3 phase
|
Output frequency range
|
0-50/60Hz
|
Rated output current
|
29A
|
Dimension(W/H/D)
|
360*500*176mm
|
weight
|
19.9kgs
|
Max. efficiency
|
98%
|
Protective class
|
I
|
Protection degree
|
IP65
|
Environment temperature
|
-25ºC-+60ºC above 60ºC need derate operation;
|
Cooling method
|
Force cooling
|
Display
|
LCD
|
Communication interface
|
GPRS
|
Altitude
|
3000m; above 3000m need derate operating
|
Noise emission
|
<50dB
|
compliance
|
EN 50178; IEC/EN 62109-1; IEC61800
|
